CC500MXL2 Masonry Saw
EZchange™ tool system features a 13 mm high segment, designed for grinding medium to hard concrete floors with a hardness level ranging from 5 to 6 on Mohs hardness scale. This carefully engineered system ensures optimal balance between tool wear and grinding speed on hard floors. With its specialised design, Elite-Grind™ EZ H allows for effective material removal and precise grinding in highly professional applications.
Specifications
| Power Source | Gasoline, Electric |
| Motor/engine manufacturer | Baldor, Briggs |
| Engine Power (As rated by the engine manufacturer) | 2 hp, 1.5 hp, 3 hp, 2.5 hp, 6.5 hp |
| Voltage | 230 V, 115-230 V, None |
| Brand | Diamond Products |
| Maximum Depth of Cut | 5" |
| Blade shaft diameter | 7/8" |
| Arbor Diameter (in) | 1" |
| Blade Shaft Bearings | Flange block ball bearings |
| Blade Shaft Drive | 2 belt |
| Blade mounting | Right (electric), Left (gas) |
| Blade raise/lower | Counterbalanced, spring tensioned head pivots on two 7/8” flange block bearings |
| Blade Coolant | Dual spray tubes, pump fed (electric models), pump from tray (gas models) |
| Air Filter | 3-stage cyclone (gas models) |
| Fuel Capacity | 1 gallon (gas models) |
| High Temp Shut-off | Included (electric models) |
| Blade Capacity | 14" |
| Phases | 1 ph |
